DB25 Male Female D-SUB RS232 Din Rail Mount Interface Module | D-sub 25Pin Terminal Block Breakout Board
US$7.80
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by barkpointventures.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
US$7.80
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by barkpointventures.com
Free 30-day returns Details
Product details
| Management number | 247549304 | Release Date | 2026/08/16 | List Price | US$7.80 | Model Number | 247549304 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- FR-4 fiber glass PCB, dual copper layers. PCB dimensions: 72.5 x85mm(W x L).
- Male and Female RS232 DB25 connectors, Screw terminal block.
- Din rail mountable - for DIN C45 width 35 / 32 / 15mm rails, Din mount case can be taken apart for panel mount use.
- Terminal block: Pitch 5.08mm/0.2" miniaturization screw terminal block. Wire range - 28-12AWG.
- External dimensions: 87 x 80 x 43mm(W x L x H).
| ASIN | B09T9PLM1R |
|---|---|
| Color | Green |
| Gauge | 12 |
| Model | JT416 |
| Pitch | 5.08 millimeters |
| Voltage | 60 volts |
| Brand Name | Jienk |
| Unit Count | 1 Count |
| Part Number | JT416 |
| Manufacturer | Jienk |
| Material Type | Copper |
| Mounting Type | DIN Rail Mount |
| Connector Type | DB25 |
| Current Rating | 1 A |
| Number Of Poles | 17 |
| Number of Items | 1 |
| Centerline Length | 8.7 centimeters |
| Number Of Contacts | 17 |
| Number of Positions | 16 |
| Item Dimensions W x H | 3.43"W x 1.69"H |
