GUYUTING 12V 200A Automotive Relay 10 Million Mechanical Life For Vehicle Split Charging High Power Electrical Application

Features:<br>High 200A coil capacity- able to handle those high current applications with ease, Heavy duty make or break (on/off) relay.<br>With 2pin footprint + 2 terminal accessories, Hundreds of uses include- starter kills, domelight supervision, trunk release, polarity change, power door lock/actuator control.<br>Made of reliable quality material, long service life.<br>The 4-pin relay switch is suitable for split charging or various automotive applications. It is ideal for most vehicles that require high-power relays, such as cars, motorcycles, and boats. <br>Package Include: 1 X Relay Split Switch Set<br><br>Specifications:<br>Contact Data:<br>Contact Form: Normal Open<br>Contact Ratings: No: 200A 14VDC<br>Contact Resistance: 100mMax at 6VDC 1A<br>Max switching Current: 500A (5ms)<br>Max Switching Voltage: 75VDC<br>Max Switching Power: 2000W<br>Life Expectancy Electrical: 100,000 Operations (at 30 Operations/min)<br>Life Expectancy Mechanical: 10,000,000 Operations<br>Coil Specification:<br>Nominal Voltage(VDC): 12V<br>Coil Resistance (4.8W/2.4W): 30/60Ω<br>Max Operate Voltage (VDC): 6.0~8.0<br>Mix Release (VDC): 1.2~3.6<br>Max Applicable Voltage (VDC): 15.6<br>Characteristics:<br>Temperature Range: -30°C ~+80°C<br>Vibration Resistance: 10~55Hz, 1.5mm<br>Shock Resistance:<br>Operations Extremes: 10g<br>Damage Limits: 100g<br>Humidity: 40%~85%<br>Insulation Resistance: 100m ohm Min at 500VDC<br>Dielectric Strength Between Open Contacts 500VAC (for one minute/sec)<br>Between Contact and coil: 750VAC (for one minute/sec)<br>Operate Time: 15ms<br>Release Time: 10ms<br><br>Package Include: <br>1 X Relay Split Switch Set

• High 200A coil capacity- able to handle those high current applications with ease, Heavy duty make or break (on/off) relay.
• With 2pin footprint + 2 terminal accessories, Hundreds of uses include- starter kills, domelight supervision, trunk release, polarity change, power door lock/actuator control.
• Made of reliable quality material, long service life.
• The 4-pin relay switch is suitable for split charging or various automotive applications. It is ideal for most vehicles that require high-power relays, such as cars, motorcycles, and boats.
• Package Include: 1 X Relay Split Switch Set
