TOF050F Laser Distance Sensor Module, VL6180 Infrared Ranging Board for Robot Obstacle Detection and DIY Measuring Projects
Product details
| Management number | 247051847 | Release Date | 2026/08/16 | List Price | US$6.00 | Model Number | 247051847 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product Description The TOF050F Time-of-Flight Distance Sensor Module is a compact and high-precision ranging solution based on the VL6180 chip. It measures distances up to 50cm (max) with a 0-2cm blind zone, making it ideal for robot obstacle avoidance, UAV altitude hold, positioning detection, and vehicle anti-collision projects. This module uses 850nm infrared emission and a 25° field of view for stable short-range distance measurement. It supports UART serial, Modbus, and IIC communication modes, giving developers flexible integration options for different controllers and systems. Operating voltage is 3.0V-5V DC, making it compatible with many embedded platforms. For easy development, routines and software support are available for Arduino, STM32F103RCT6, Raspberry Pi, and PC debugging, along with a full serial command set. The board features a dedicated optical cover for dust protection and optical filtering, plus a shielded design to help reduce electromagnetic interference and protect peripheral circuits. A PH1.0mm 6-pin connector enables convenient plug-and-play wiring, while M2 gold-plated mounting holes make installation easier in compact projects. Specifications: Model: TOF050F Chip: VL6180 Max Measuring Distance: 50cm Blind Zone: 0-2cm Modes: High Precision 200mm / Medium 400mm / Long Distance 500mm IR Wavelength: 850nm FOV: 25° Communication: UART / Modbus / IIC Operating Voltage: 3.0V-5V DC Max Working Current: 40mA Operating Temperature: -20°C to 70°C
- 【TOF200F Distance Sensor】This laser distance sensor module helps measure object distance in DIY projects.
- 【VL53L0X Style Ranging】Great for robots, drones, proximity checks, and smart devices.
- 【Optical Feedback】Time of flight sensing gives clean distance data for control tasks.
- 【Small Board】Compact size fits cars, handheld tools, and small enclosures.
- 【Maker Sensor】A practical TOF distance module for electronics and measuring projects.
| ASIN | B0H2MM3LC2 |
|---|---|
| Color | TOF200F Board |
| Brand Name | MakerCircuit |
| Sport Type | Climbing |
| Manufacturer | MakerCircuit |
| Material Type | Plastic |
| Included Components | TOF distance sensor |
| Warranty Description | 2 Year Manufacturer |
| Manufacturer Part Number | TOF distance sensor |
